EHC Cells – Wedge Cells
Product Details
International standard EHC cells
Perfect for quality control of liquid crystal materials.
For further information, please contact us or download our catalog.
Product Specifications
[Orientation Film]
○Polyimide resin: LX-1400 (Manufactured by Hitachi Chemical Co., Ltd.)
○Film manufacturing method: Spin coating
[Rubbing]
○Rubbing roll
→Fiber: Polyester
→Fiber length: 8mm
→Roll diameter: 58mm
○Rubbing conditions
→Roll revolution speed: 600rpm
→Movement speed: 30mm/sec
→Count: 3 full revolutions
○Sealing agent: UV-curable resin (acrylic)
